Standards
– IEEE 802.11b/g/n
Port Type
– USB1.1/USB2.0
Frequency Range
– 2.412-2.472GHZ
Mode Channels
– 1-13(according to different regions)
Modulation Type
– OFDM/CCK/16-QAM/64-QAM
Receiver Sensitivity
– 1M:-95dBm @ 8% PER
– 11M:-89dBm @ 8% PER
– 54M:-73dBm @ 10% PER
– 150M:-69dBm @ 10% PER
Work Mode
– Infrastructure
Spread Spectrum Technology
– DSSS (Direct Sequence Spread Spectrum)
Wireless Transmission Power
– 18dbm (MAX)
Transmission Range
– Indoor 80 meters at most;
– Outdoor100 meters at most (depends on environment)
Supported Operating Systems
– WinXP/Win7/Win8/Win8.1/Win10
Environment
– Operating temperature: 0℃~40℃
– Storage temperature: -40℃~70℃
– Operating humidity: 10%~90%RH,Noncondensing
– Storage humidity: 5%~90%RH,Noncondensing
